SciAps Z-200C+ LIBS Analyzer
The SciAps Z-200C+ LIBS Analyzer is a handheld carbon and alloy analyzer designed for fast field analysis of steels and stainless steels. Using LIBS technology, integrated argon purge, carbon-specific spectroscopy, and laser rastering, it provides an efficient solution for carbon measurement, alloy verification, PMI, and carbon equivalent testing.
Description
SciAps Z-200C+ LIBS Analyzer – Handheld Carbon & Alloy Analyzer for PMI and Metal Identification
The SciAps Z-200C+ LIBS Analyzer is a professional handheld Laser-Induced Breakdown Spectroscopy (LIBS) analyzer designed for rapid carbon analysis and alloy identification. It is particularly useful for distinguishing carbon and stainless steels, verifying carbon content, calculating carbon equivalents, and supporting Positive Material Identification (PMI) applications.
The analyzer uses a pulsed 1064 nm laser and an integrated argon purge system to improve analytical performance. Its compact handheld design allows technicians to perform measurements directly in the field, reducing the need to transport samples to a laboratory for every inspection.
Main Benefits
Rapid carbon analysis in steels and stainless steels
Supports carbon equivalent calculations
Handheld design for field inspection
Helps distinguish L-grade and H-grade stainless steels
Supports alloy identification and PMI
Small laser spot for targeted analysis
Integrated argon purge for carbon measurements
Laser rastering across multiple measurement points
Reduces dependence on laboratory testing
Suitable for pipelines, fabrication, and industrial inspection
Key Features
Handheld LIBS technology
Dedicated carbon analysis capability
1064 nm pulsed laser
50 Hz laser repetition rate
Integrated argon purge
Carbon calibration from 0–1% as specified for the standard carbon application
Carbon Equivalent calculations
Mn:C ratio calculations
Residual element calculations
Six-point laser rastering and averaging
High-resolution carbon spectrometer
Built-in camera
Wi-Fi and Bluetooth connectivity
GPS
USB connectivity
Rechargeable battery
User-configurable calibration capability through Profile Builder software
Key Specifications
Product Type: Handheld LIBS Analyzer
Model: SciAps Z-200C+
Technology: Laser-Induced Breakdown Spectroscopy (LIBS)
Primary Application: Carbon and alloy analysis
Laser Wavelength: 1064 nm
Laser Energy: Approximately 5.5 mJ/pulse
Repetition Rate: 50 Hz
General Spectrometer Range: 190–620 nm
Carbon Spectrometer: 193 nm carbon region
Carbon Calibration: 0–1% for the standard carbon application
Argon Purge: On-board, user-replaceable cartridge
Laser Spot: Less than 100 µm
Measurement Method: Laser rastering across multiple locations
Connectivity: Wi-Fi, Bluetooth, USB
Navigation: GPS
Battery: Rechargeable battery
Software: Profile Builder and SciAps Z software platform
Applications
The SciAps Z-200C+ LIBS Analyzer is ideal for:
Positive Material Identification (PMI)
Carbon steel analysis
Stainless steel analysis
L-grade stainless steel verification
Carbon equivalent measurement
Weldability assessment
Pipeline inspection
Oil and gas inspection
Metal fabrication
Quality control
Scrap metal identification
Alloy verification
Industrial maintenance
Refinery inspection
Petrochemical inspection
SciAps specifically describes applications involving carbon measurement in stainless steels, carbon equivalents in pipeline steels, and residual element analysis in industrial environments.
What is the SciAps Z-200C+ used for?
The Z-200C+ is primarily used for carbon analysis in steels and stainless steels, alloy identification, carbon equivalent calculations, and PMI applications.
Can it measure carbon in stainless steel?
Yes. The Z-200C+ was specifically developed for carbon analysis in stainless and carbon steels and can help distinguish different stainless-steel grades based on carbon content.
What laser does the Z-200C+ use?
It uses a 1064 nm pulsed laser operating at approximately 5.5 mJ per pulse and 50 Hz.
Does it require argon?
For high-performance carbon analysis, the Z-200C+ uses an on-board replaceable argon purge cartridge. SciAps states that the cartridge provides approximately 125–150 carbon analyses, depending on the testing method.
Can it calculate Carbon Equivalent?
Yes. The Z-200C+ carbon application includes Carbon Equivalent calculations, along with Mn:C ratio and residual-element calculations.
Is sample grinding required?
For carbon analysis, proper surface preparation and grinding are recommended. SciAps describes specific grinding procedures for reliable carbon measurements, while its broader Z-series LIBS platform can perform many alloy identification applications without grinding
