SciAps Z-901 Li Lithium Geo LIBS Analyzer
The SciAps Z-901 Li Lithium Geo LIBS Analyzer is a dedicated handheld lithium analyzer designed for rapid geological analysis in the field. With a 380–680 nm spectral range, 100 µm laser spot, lithium-specific calibration, laser rastering, integrated cameras, GPS, and wireless connectivity, it provides an efficient solution for lithium exploration and geochemical analysis.
Description
SciAps Z-901 Li Lithium Geo LIBS Analyzer – Handheld Lithium Analyzer for Rocks, Ores & Soils
The SciAps Z-901 Li Lithium Geo LIBS Analyzer is a specialized handheld Laser-Induced Breakdown Spectroscopy (LIBS) instrument designed specifically for lithium analysis in geological materials. It provides rapid, in-field elemental analysis of lithium in rocks, ores, powders, and soils, making it a valuable tool for lithium exploration and geochemical investigation.
The Z-901 Li operates across a 380–680 nm spectral range and is factory calibrated for lithium in materials including pegmatites, clays, and mica-schists, with relevant matrix elements included in the calibration.
Its compact handheld design, integrated cameras, laser rastering, GPS, Wi-Fi, Bluetooth, and rechargeable battery make it suitable for both field exploration and laboratory-supported analysis.
Main Benefits
Dedicated lithium analysis
Fast in-field geological testing
Designed for rocks, ores, powders, and soils
No need to send every sample to a laboratory
100 µm laser spot for targeted analysis
Laser rastering for localized or averaged measurements
Lightweight handheld design
Built-in camera for precise sample targeting
GPS, Wi-Fi, and Bluetooth connectivity
Suitable for lithium exploration projects
Key Features
Handheld LIBS technology
Dedicated lithium calibration
380–680 nm spectral range
Factory calibration for pegmatites, clays, and mica-schists
100 µm laser spot size
Integrated Y-stage for laser rastering
Integrated sample-viewing camera
Macro camera for documentation and QR/barcode scanning
3.5-inch high-brightness touchscreen
Automated drift correction
Opti-Purge inert argon environment
Built-in GPS
Wi-Fi and Bluetooth connectivity
USB-C connectivity
Rechargeable lithium-ion battery
32 GB SD card for results storage
Rugged metal housing for field use
Key Specifications
Product Type: Handheld LIBS Analyzer
Model: Z-901 Li
Primary Application: Lithium analysis
Technology: Laser-Induced Breakdown Spectroscopy (LIBS)
Spectral Range: 380–680 nm
Laser Spot Size: 100 µm
Sample Types: Rocks, ores, powders, soils
Factory Calibration: Lithium in pegmatites, clays, and mica-schists
Display: 3.5-inch high-brightness color touchscreen
Data Storage: 32 GB SD card
Weight: Approximately 1.75 kg with battery
Connectivity: Wi-Fi, Bluetooth, GPS, USB-C
Power: Rechargeable Li-ion battery
Operating Time: 6+ hours depending on use
Atmosphere: Opti-Purge argon environment
Laser Raster: Integrated Y-stage
Sample Viewing: Integrated camera and laser target indicator
Macro Camera: For sample documentation and barcode/QR-code reading
Applications
The SciAps Z-901 Li Lithium Geo LIBS Analyzer is ideal for:
Lithium exploration
Mineral exploration
Geological field surveys
Lithium-bearing rock analysis
Pegmatite analysis
Clay analysis
Mica-schist analysis
Ore grade investigation
Geochemical exploration
Strategic mineral exploration
Mining research
Academic geological research
Field screening and sample characterization
What is the SciAps Z-901 Li used for?
The Z-901 Li is designed primarily for lithium analysis in rocks, ores, powders, and soils, particularly for geological and lithium exploration applications.
What type of technology does it use?
It uses Laser-Induced Breakdown Spectroscopy (LIBS), an optical emission spectroscopy technique that uses a focused laser pulse to create a plasma and measure elemental composition.
What materials can the Z-901 Li analyze?
It is factory calibrated for lithium analysis in pegmatites, clays, and mica-schists, and is designed for geological samples including rocks, ores, powders, and soils.
What is the laser spot size?
The Z-901 Li provides a 100 µm laser spot size, allowing targeted microanalysis of specific areas of a sample.
Can the laser analyze multiple locations on a sample?
Yes. The integrated Y-stage allows the laser to raster across discrete locations for targeted analysis or averaging.
Is the Z-901 Li suitable for field work?
Yes. Its handheld design, approximately 1.75 kg weight with battery, integrated cameras, GPS, wireless connectivity, rechargeable battery, and rugged metal housing are designed for field and laboratory use.
