Leica Absolute AT500 Laser Tracker System
The Leica Absolute AT500 Laser Tracker System is a high-precision 3D measurement system designed for industrial metrology, large-scale inspection, and manufacturing applications. It combines advanced laser tracking technology, absolute distance measurement, and portable operation to deliver accurate 3D measurements for aerospace, automotive, shipbuilding, energy, and precision manufacturing industries.
With an integrated controller, battery-powered operation, wireless connectivity, and support for 6DoF probing, the AT500 provides a flexible solution for measuring large components, assemblies, and complex structures directly on the production floor.
Description
Leica Absolute AT500 Laser Tracker System – High Precision 3D Measurement Solution for Industrial Metrology & Large-Scale Inspection
The Leica Absolute AT500 Laser Tracker System is a professional LiDAR & Laser Scanning Equipment solution designed for high-accuracy industrial measurement and large-scale inspection. Built with advanced laser tracking and absolute distance measurement technology, it enables manufacturers to capture precise 3D coordinates for complex components, assemblies, and structures.
Featuring a portable design, integrated controller, battery-powered operation, IP54 protection, and 6DoF probing capability, the AT500 delivers reliable performance in demanding manufacturing environments.
The Leica Absolute AT500 Laser Tracker System is an ideal solution for aerospace, automotive, industrial manufacturing, energy, and engineering companies requiring accurate, portable, and efficient 3D measurement technology.
Main Benefits
High-Precision 3D Measurement
Provides accurate dimensional measurement for quality control, assembly verification, and industrial inspection workflows.
Portable Large-Scale Metrology
Designed for flexible measurement directly at manufacturing sites, production lines, and large industrial environments.
Wireless & Cable-Free Operation
Built-in controller and battery operation simplify setup and allow measurements in challenging locations.
Large Measurement Volume
Supports large-scale inspection tasks with reflector measurement capability across a large working volume.
Improved Productivity
Fast setup, one-button operation, and advanced probing options help reduce inspection time.
Key Features
Absolute Distance Measurement Technology
Uses advanced laser tracking technology to provide reliable 3D positioning and dimensional measurement.
Integrated Controller & Battery System
The compact design includes built-in control electronics and battery power for easier transportation and setup.
6DoF Measurement Capability
Supports handheld probing solutions such as B-Probeplus for measuring hidden points and complex geometries.
High-Speed Measurement
Provides dynamic measurement performance suitable for industrial inspection workflows.
IP54 Environmental Protection
Designed for reliable operation in industrial environments with protection against dust and water exposure.
Extended Operating Temperature Range
Operates in challenging environments from approximately -15°C to +50°C.
Large Measurement Range
Supports reflector measurement distances suitable for large structures and industrial equipment inspection.
Wireless Connectivity
Provides flexible setup and communication options for modern manufacturing environments.
Specifications
Product Type: Industrial Laser Tracker System
Category: LiDAR & Laser Scanning Equipment
Subcategory: Laser Tracker Systems / Industrial 3D Measurement Systems
Manufacturer: Leica Geosystems / Hexagon Manufacturing Intelligence
Measurement Technology:
Laser tracking
Absolute Distance Measurement (ADM)
3D coordinate measurement
Measurement Range:
Up to approximately 320 m diameter measurement volume
Measurement Accuracy:
Approximately ±15 μm + 6 μm/m (MPE)
Dynamic Measurement Rate:
Up to 10 Hz
Measurement Angles:
Horizontal: ±360°
Vertical: ±145°
Device Weight:
Approx. 13.6 kg
Protection Rating:
IP54
Operating Temperature:
-15°C to +50°C
Laser Class:
Class 2
Compatible Accessories:
Reflectors
B-Probeplus handheld probe
Laser tracker accessories
Applications
Aerospace Manufacturing
Used for aircraft component inspection, assembly alignment, and precision measurement.
Automotive Production
Supports vehicle body inspection, tooling verification, and manufacturing quality control.
Industrial Equipment Inspection
Measures large machinery, structures, and precision assemblies.
Shipbuilding & Marine Engineering
Provides accurate dimensional verification for large-scale components.
Power & Energy Industry
Supports inspection and alignment of large industrial equipment.
Manufacturing Quality Control
Helps verify product dimensions, tooling accuracy, and assembly processes.
What is the Leica Absolute AT500 Laser Tracker System used for?
The Leica Absolute AT500 is used for high-precision 3D measurement, industrial inspection, assembly alignment, and large-scale metrology applications.
Is the AT500 a 3D scanner?
The AT500 is primarily a laser tracker and precision measurement system rather than a traditional point-cloud 3D scanner. It measures precise 3D coordinates using laser tracking technology.
What industries use Leica AT500?
It is commonly used in aerospace, automotive, manufacturing, shipbuilding, energy, and industrial engineering applications.
Can the AT500 measure large objects?
Yes. It is designed for large-volume measurement projects, including large structures, machinery, and industrial assemblies.
Does Leica AT500 work outdoors?
Yes. Its IP54 protection and extended operating temperature range allow operation in various industrial environments.
What accessories can be used with AT500?
The system supports reflectors, handheld probes such as B-Probeplus, and other laser tracker accessories for flexible measurement workflows.
