DEKA SmartXide Punto CO₂ Laser 2024

Description

DEKA SmartXide Punto CO₂ Laser 2024 – Advanced Fractional Skin Resurfacing & Dermatology System

The DEKA SmartXide Punto CO₂ Laser 2024 is a premium Aesthetic Laser System developed for advanced skin resurfacing, dermatologic surgery, and aesthetic rejuvenation. Combining a powerful 10,600 nm RF-excited CO₂ laser with exclusive Pulse Shape Design (PSD) technology, the system provides exceptional control over ablation depth, thermal effects, and treatment customization for a wide range of skin conditions.

Featuring the Hi-Scan DOT fractional scanning system, SmartStack technology, and support for CoolPeel treatments, SmartXide Punto enables clinicians to perform effective wrinkle reduction, scar revision, skin tightening, pigmentation correction, and dermatologic surgery while minimizing downtime and maximizing patient comfort. Its intuitive touchscreen interface, customizable scanning patterns, and reliable RF CO₂ laser source make it a trusted solution for dermatology clinics, medical spas, plastic surgeons, and aesthetic practices.

Main Benefits

Advanced Fractional CO₂ Resurfacing
Improves skin texture, fine lines, wrinkles, scars, and pigmentation with controlled fractional laser technology.

Customized Pulse Control
PSD (Pulse Shape Design) technology allows clinicians to select different pulse shapes for precise tissue interaction and optimized treatment outcomes.

Minimal Downtime
CoolPeel and high-peak pulse technology deliver effective resurfacing while reducing thermal damage and shortening recovery time.

Versatile Clinical Applications
Suitable for facial rejuvenation, acne scars, surgical procedures, skin tightening, benign lesion removal, and aesthetic gynecology with optional accessories.

Reliable RF CO₂ Technology
RF-excited CO₂ laser source provides consistent performance, long service life, and low maintenance requirements.

Key Features

RF CO₂ Laser Technology
CO₂ RF laser source
Wavelength: 10,600 nm
Available in 30 W and 50 W configurations.

Pulse Shape Design (PSD)
Supports multiple pulse modes including:
CW
SmartPulse (SP)
D-Pulse (DP)
H-Pulse (HP)
for customized tissue ablation and coagulation.

Hi-Scan DOT Scanner
Provides adjustable scan parameters for precise fractional resurfacing with multiple scan shapes and SmartTrack scanning modes.

CoolPeel Technology
Performs superficial CO₂ resurfacing with reduced downtime while improving skin tone and texture.

SmartStack Technology
Offers up to 5 stacking levels for precise control of ablation depth and thermal effect.

Customizable Scan Patterns
Available scan shapes include:
Point
Line
Triangle
Square
Ellipse
Hexagon
Ring.

User-Friendly Interface
Large touchscreen display with programmable treatment protocols for fast and intuitive operation.

Low Maintenance Design
RF metal-ceramic laser source is designed for durability and reduced maintenance costs.

Specifications

Product Type: Fractional CO₂ Laser System
Category: Aesthetic Laser Systems
Subcategory: Fractional CO₂ Laser Systems
Manufacturer: DEKA
Laser Technology
RF Excited CO₂ Laser
Wavelength
10,600 nm
Power Options
30 W
50 W
Pulse Modes
CW
SmartPulse
D-Pulse
H-Pulse
Scanner
Hi-Scan DOT
Maximum Scan Area
15 × 15 mm
Scan Modes
Normal
Interlaced
SmartTrack
SmartStack
Levels 1–5
DOT Spacing
0–2,000 μm
Dwell Time
100–2,000 μs
Display
Color touchscreen interface
Electrical Requirements
100–230 VAC
50/60 Hz
Weight
Approximately 60 kg
Laser Class
Class 4 Medical Laser

Applications

Fractional Skin Resurfacing
Improves skin texture, pores, and overall skin quality.

Wrinkle Reduction
Treats fine lines and moderate facial wrinkles.

Acne Scar Revision
Reduces acne scars and post-surgical scars.

Stretch Mark Treatment
Improves the appearance of striae and stretch marks.

Pigmented Lesions
Treats selected benign pigmented skin lesions.

Dermatologic Surgery
Performs precise skin excisions and minor surgical procedures.

Skin Tightening
Stimulates collagen remodeling for firmer, smoother skin.

Aesthetic Gynecology
Compatible with optional accessories for specialized gynecologic procedures.

What is the DEKA SmartXide Punto CO₂ Laser 2024?
It is a professional fractional CO₂ laser platform designed for skin resurfacing, scar treatment, wrinkle reduction, dermatologic surgery, and aesthetic procedures.

What wavelength does the SmartXide Punto use?
The system operates at a 10,600 nm CO₂ wavelength.

What makes PSD® technology unique?
PSD® allows clinicians to select different pulse shapes to control tissue vaporization and thermal effects according to the treatment indication.

Does the SmartXide Punto support CoolPeel treatments?
Yes. The system supports CoolPeel, enabling effective skin rejuvenation with reduced downtime.

What treatments can be performed?
It can treat wrinkles, acne scars, skin laxity, pigmentation, stretch marks, benign lesions, and perform dermatologic surgical procedures.

Is the system available in different power configurations?
Yes. SmartXide Punto is available in 30 W and 50 W models to meet different clinical requirements.
